The ASRock WRX80 Creator R2.0 WIFI is a workstation motherboard designed for high-performance computing. It is built for professionals who need extreme stability, connectivity, and upgrade headroom.

Full specifications ↓

Highlights

Supports AMD Ryzen Threadripper PRO 3000WX and 5000WX series processors.
Offers a massive maximum system memory capacity of up to 2048 GB.
Equipped with 7 PCIe 4.0 x16 slots for extensive hardware expansion.
Features Dual Marvell (Aquantia) 10GbE LAN for high-speed networking.
Includes Intel WiFi 6E and Bluetooth 5.3 for wireless connectivity.
Built with a 14-layer server-grade low-loss PCB for reliable performance.
Provides 8 SATA3 6.0 Gb/s ports for multiple storage connections.
Includes 2 Thunderbolt 4 Type-C ports for fast data transfer.

Specifications

CPU Support	AMD Socket sWRX8 for AMD Ryzen™ Threadripper™ PRO 5000WX and 3000WX Series Processors
Power Design	8 Power Phase Design, 105A SPS
Memory Slots	8 x DDR4 DIMM Slots
Memory Support	Supports DDR4 4533+(OC)
Memory Type Support	Supports DDR4 ECC & non-ECC, buffered and un-buffered memory (U-DIMM) up to 4400+(OC)
Memory Type Support (R-DIMM)	Supports DDR4 3200 / 2933 / 2667 / 2400 / 2133 ECC & non-ECC, buffered and un-buffered memory (R-DIMM and 3DS R-DIMM)
Max. capacity of system memory	2048 GB
Expansion Slots	7 x PCIe 4.0 x16 Slots (PCIE1/PCIE2/PCIE3/PCIE5/PCIE7 at x16; PCIE4/PCIE6 at x8)
M.2 Socket (CPU)	1 x Hyper M.2 Socket (M2_1, Key M), supports type 2260/2280/22110 SATA3 6.0 Gb/s & PCIe Gen4x4 (64 Gb/s) modes
M.2 Socket (Chipset)	1 x Hyper M.2 Socket (M2_2, Key M), supports type 2260/2280 PCIe Gen4x4 (64 Gb/s) mode
SATA Ports	8 x SATA3 6.0 Gb/s Connec
Dedicated IPMI LAN	1 x Dedicated IPMI (ASPEED AST2500)
Wireless	Intel® 802.11ax (WiFi 6E) + Bluetooth 5.3
USB Ports	2 Thunderbolt 4 Type-C, 5 USB 3.2 Gen2 (1 Front Type-C, 4 Rear), 6 USB 3.2 Gen1 (4 Front, 2 Rear)
Audio	7.1 CH HD Audio (Realtek ALC4050H+ALC1220), Nahimic Audio
BIOS	256Mb AMI UEFI Legal BIOS with GUI support
Voltage Multi-adjustment	CPU, CPU VDDCR_SOC, DRAM, VPPM, PREM VDD_CLDO, PERM VDDCR_SOC, +1.8V, VDDP
BMC Controller	Aspeed AST2500 BMC Controller (Supports D-Sub with max. resolution up to 1920x1200 @ 60Hz)

Who should buy it

This is for professionals building a high-end workstation who need massive memory and expansion. Users looking for a standard home PC motherboard should consider other models.

Compatibility

It works with AMD Ryzen Threadripper PRO 3000WX and 5000WX series processors. It supports DDR4 ECC and non-ECC memory, including U-DIMM and R-DIMM types.

AMD Ryzen Threadripper PRO 3000WX/5000WX Series Processors
Supports DDR4 ECC & non-ECC, buffered and un-buffered memory (U-DIMM) up to 4400+(OC)
Supports AMD 4-Way CrossFireX™, 3-Way CrossFireX™ and CrossFireX™

What's in the box

ASRock WRX80 Creator R2.0 WIFI Workstation Motherboard

Frequently asked questions

Which processors are compatible with this motherboard?

It supports AMD Ryzen Threadripper PRO 5000WX and 3000WX series processors.

How many memory slots are available?

The motherboard features 8 x DDR4 DIMM slots.

What is the maximum memory capacity?

The system supports a maximum memory capacity of 2048 GB.

Does it have high-speed networking?

Yes, it features Dual Marvell (Aquantia) 10GbE LAN and Intel WiFi 6E.
