MasterBox TD500 Mesh V2 - three-quarter front-left view of black Cooler Master MasterBox TD500 Mesh V2 with RGB fans

Cooler Master MasterBox TD500 Mesh V2 Black Mid Tower Cabinet (TD500V2-KGNN-S00)

₹8,049

MRP ₹13,099 (incl. of all taxes)

🚚 Shipping ₹379 · FREE on orders above ₹25,000

In stock · dispatched in 1–2 working days
Delivery across India in 2–8 days · insured

Genuine productBrand warranty
GST invoiceClaim input credit
7-day returnsOn PC components
Insured deliveryAll over India

Secure payments by Razorpay · UPI, cards, net banking, EMI

Track an order Google reviews ↗

The MasterBox TD500 Mesh V2 is a mid-tower PC case with a polygonal fine-mesh front, tempered glass side panel and three pre-installed CF120 ARGB front fans. It is designed for gaming and high-airflow builds and is sold by TechCure India with delivery across India.

Full specifications ↓

Highlights

Polygonal fine-mesh front panel for improved airflow and dust filtration.
Three CF120 ARGB fans pre-installed at the front for immediate ARGB lighting and airflow.
USB 3.2 Gen 2 Type-C port on the I/O panel for fast connectivity.
Tool-free crystalline tempered glass side panel for easy viewing and access.
Supports large cooling setups: front/top radiators up to 360mm and top recommended thickness up to 55mm.
Clearances: up to 165mm CPU cooler height and up to 410mm GPU length.
Bottom-mount ATX power supply support with recommended PSU length up to 170mm to ease cable management.
Dust filters included on front, top and bottom to reduce dust intake.

Specifications

Model Number	TD500 Mesh V2: TD500V2-KGNN-S00, TD500 Mesh V2 White: TD500V2-WGNN-S00
Exterior Color	Black, White
Materials - Exterior	Steel, Mesh, Plastic
Materials - Left Side Panel	Tempered Glass
Dimensions (L x W x H)	499 x 210 x 500mm (incl. Protrusions), 430 x 210 x 477mm (excl. Protrusions)
Motherboard Support	Mini-ITX, Micro-ATX, ATX, SSI-CEB, E-ATX* (*up to 12" x 10.7" motherboards, may impact cable management feature)
Expansion Slots	7
3.5" Drive Bays	2
2.5" Drive Bays	3
I/O Panel - USB Ports	2x USB 3.2 Gen 1, 1x USB 3.2 Gen 2 type C
I/O Panel - Audio In / Out	1x Audio Jack
I/O Panel - Other	1x ARGB Fan Hub
Pre-installed Fans - Top	N/A
Pre-installed Fans - Front	3x 120mm CF120 ARGB
Pre-installed Fans - Rear	N/A
Fan Support - Top	3x 120mm, 2x 140mm
Fan Support - Front	3x 120mm, 2x 140mm
Fan Support - Rear	1x 120mm
Radiator Support - Top	120 / 140 / 240 / 280 / 360mm (recommended maximum thickness - 55mm)
Radiator Support - Front	120 / 140 / 240 / 280 / 360mm
Radiator Support - Rear	120mm
Clearance - CPU Cooler	165mm
Clearance - PSU	200mm (Recommended up to 170mm)
Clearance - GFX	410mm
Cable Routing - Behind Motherboard Tray	19mm / 0.74"
Dust Filters	Front, Top, Bottom
Power Supply Support	Bottom Mount, ATX
Warranty	2 years
Size	Mid Tower
Series	MasterBox Series

Who should buy it

Choose this case if you want a gaming-focused mid-tower with strong front airflow, ARGB lighting and a tempered glass side. If you need extensive cable routing space for very large E-ATX boards or very long PSUs beyond 170mm recommended for neat cable management, consider other options.

Compatibility

Works with Mini-ITX, Micro-ATX and ATX motherboards; E-ATX/SSI-CEB up to 12" x 10.7" can fit but may impact cable management. Uses bottom-mount ATX power supplies (recommended up to 170mm) and supports multiple radiator sizes front/top up to 360mm and rear 120mm.

Compatible with Mini-ITX, Micro-ATX, ATX; E-ATX / SSI-CEB up to 12" x 10.7" (may impact cable management).
Supports up to seven 120mm fans and multiple radiator sizes (front/top up to 360mm).
Power supply: Bottom mount ATX; recommended PSU length up to 170mm (clearance listed as 200mm).

What's in the box

3x 120mm CF120 ARGB fans (pre-installed, front)

Frequently asked questions

Does this exact model (TD500V2-KGNN-S00) include the three CF120 ARGB fans out of the box?

Yes. This model ships with three 120mm CF120 ARGB fans pre-installed in the front.

What are the exact GPU (GFX) length and CPU cooler height clearances?

GPU clearance is 410mm and CPU cooler clearance is 165mm.

Is USB Type-C on the I/O panel USB 3.2 Gen 2 as listed?

Yes. The I/O panel includes one USB 3.2 Gen 2 Type-C port.

Can an E-ATX/SSI-CEB motherboard up to 12" x 10.7" be installed without significant modification?

An E-ATX/SSI-CEB board up to 12" x 10.7" can be installed, but it may impact the case's cable management features.

What is the recommended maximum PSU length to maintain cable management?

While PSU clearance is listed as 200mm, the recommended PSU length to maintain cable management is up to 170mm.

Are dust filters included on front, top and bottom?

Yes. The case includes dust filters on the front, top and bottom.

Does the case include an ARGB hub and where is it located?

The I/O panel lists one ARGB fan hub; the facts state an ARGB fan hub is included on the I/O panel.

Is the tempered glass side panel tool-free on this model?

Yes. The tempered glass side panel is described as tool-free.

Brand warranty: 2 years from the manufacturer — TechCure India helps you with the claim.

Why buy from TechCure India

Genuine product with brand warranty
GST invoice on every order
Insured delivery across India
Free compatibility check before dispatch — or build a full PC with our PC Builder

Cooler Master MasterBox TD500 Mesh V2 Black Mid... — specifications

Brand	Cooler Master
Category	PC Cabinet
Model / MPN	TD500V2-KGNN-S00
Model Number	TD500 Mesh V2: TD500V2-KGNN-S00, TD500 Mesh V2 White: TD500V2-WGNN-S00
Exterior Color	Black, White
Materials - Exterior	Steel, Mesh, Plastic
Materials - Left Side Panel	Tempered Glass
Dimensions (L x W x H)	499 x 210 x 500mm (incl. Protrusions), 430 x 210 x 477mm (excl. Protrusions)
Motherboard Support	Mini-ITX, Micro-ATX, ATX, SSI-CEB, E-ATX* (*up to 12" x 10.7" motherboards, may impact cable management feature)
Expansion Slots	7
3.5" Drive Bays	2
2.5" Drive Bays	3
I/O Panel - USB Ports	2x USB 3.2 Gen 1, 1x USB 3.2 Gen 2 type C
I/O Panel - Audio In / Out	1x Audio Jack
I/O Panel - Other	1x ARGB Fan Hub
Pre-installed Fans - Top	N/A
Pre-installed Fans - Front	3x 120mm CF120 ARGB
Pre-installed Fans - Rear	N/A
Fan Support - Top	3x 120mm, 2x 140mm
Fan Support - Front	3x 120mm, 2x 140mm
Fan Support - Rear	1x 120mm
Radiator Support - Top	120 / 140 / 240 / 280 / 360mm (recommended maximum thickness - 55mm)
Radiator Support - Front	120 / 140 / 240 / 280 / 360mm
Radiator Support - Rear	120mm
Clearance - CPU Cooler	165mm
Clearance - PSU	200mm (Recommended up to 170mm)
Clearance - GFX	410mm
Cable Routing - Behind Motherboard Tray	19mm / 0.74"
Dust Filters	Front, Top, Bottom
Power Supply Support	Bottom Mount, ATX
Warranty	2 years
Size	Mid Tower
Series	MasterBox Series
