FRACTAL DESIGN Define 7 XL Dark EATX Full Tower Cabinet (Black Solid)

₹30,798
Skip to product information
FRACTAL DESIGN Define 7 XL Dark EATX Full Tower Cabinet Model FD-C-DEF7X-01 – Define 7 XL Black Solid – TechCure India
  • FRACTAL DESIGN Define 7 XL Dark EATX Full Tower Cabinet Model FD-C-DEF7X-01 – Define 7 XL Black Solid – TechCure India
  • FRACTAL DESIGN Define 7 XL Dark EATX Full Tower Cabinet (Black Solid) Model FD-C-DEF7X-01 – photo 2 – TechCure India
  • FRACTAL DESIGN Define 7 XL Dark EATX Full Tower Cabinet (Black Solid) Model FD-C-DEF7X-01 – photo 3 – TechCure India
  • FRACTAL DESIGN Define 7 XL Dark EATX Full Tower Cabinet Model FD-C-DEF7X-01 – Define 7 XL Black Solid – TechCure India
  • FRACTAL DESIGN Define 7 XL Dark EATX Full Tower Cabinet (Black Solid) Model FD-C-DEF7X-01 – photo 2 – TechCure India
  • FRACTAL DESIGN Define 7 XL Dark EATX Full Tower Cabinet (Black Solid) Model FD-C-DEF7X-01 – photo 3 – TechCure India
FRACTAL DESIGN Define 7 XL Dark EATX Full Tower Cabinet (Black Solid)

FRACTAL DESIGN Define 7 XL Dark EATX Full Tower Cabinet (Black Solid)

₹30,798

🚚 Free shipping across India on this product

EMI available at checkout (credit / debit card EMI via Razorpay)

In stock · dispatched in 1–2 working days
Delivery across India in 2–8 days · insured

  • Genuine productBrand warranty · terms
  • GST invoiceClaim input credit
  • 7-day returnsOn PC components
  • Insured deliveryAll over India

Secure payments by Razorpay · UPI, cards, net banking, EMI

  • American Express
  • Diners Club
  • Maestro
  • Mastercard
  • RuPay
  • Visa
Track an order Google reviews ↗

The Define 7 XL Black Solid is a full tower computer case designed for builders who want a versatile and quiet system. It supports large motherboards, multiple storage drives, and high-performance cooling setups.

Full specifications ↓

Highlights

  • Supports up to 18 HDDs and 5 SSDs mounts for massive storage needs.
  • Includes 3 pre-installed Dynamic X2 GP-14 fans for excellent airflow.
  • Industrial sound damping ensures whisper-quiet operation during use.
  • Dual-layout interior accommodates E-ATX, SSI-EEB, and other large motherboards.
  • Front, top, and bottom dust filters keep your system clean.
  • 30 mm cable routing space for neat and organized builds.
  • Front fan mounts support 4x 120 mm or 3x 140 mm fans.
  • Rear fan mounts support 1x 120/140 mm fan.

Specifications

Type Define 7 XL Black Solid
Compatible products 01 02
Color Black
Dedicated 2.5" drive mounts 5
5.25" drive mounts 0
Combined 3.5"/2.5" drive mounts 6
Expansion slots 9
Front interface 2x USB 2.0 Type-A, 2x USB Type-A 5Gbps, 1x USB Type-C 20Gbps, 1x Audio Jack, 1x Microphone Jack, 1x Power Button, 1x Reset Button
Captive thumbscrews HDD brackets, SSD brackets, PSU bracket
Left side panel Steel
Right side panel Steel
Dust filters Front Dust Filter, Top Dust Filter, Bottom Dust Filter, PSU Dust Filter
Cable grommets Yes
Hook-and-loop straps Cable routing space
Cable routing space 30 mm
Front fan mounts 4x 120 mm or 3x 140 mm
Top fan mounts 4x 120 mm or 3x 140 mm
Bottom fan mounts 2x 120/140 mm
Rear fan mounts 1x 120/140 mm
Fans included 2x Dynamic X2 GP-14 (front), 1x Dynamic X2 GP-14 (rear)
Motherboard compatibility E-ATX, ATX, Micro ATX, Mini ITX, EE-ATX, SSI-CEB, SSI-EEB
PSU compatibility ATX
PSU max length 250 mm
GPU max length 530 mm
CPU cooler max height 185 mm
Top radiator compatibility 120, 140, 240, 280, 360, 420, 480
Front radiator compatibility 120, 140, 240, 280
Bottom radiator compatibility 120, 140, 240, 280
Rear radiator compatibility 120
Product dimensions (L × W × H) 604 x 240 x 566 mm
Package dimensions (L × W × H) 646 x 357 x 708 mm
Volume (L) 77.6 L
Net weight 16.5 kg
Gross weight 20.2 kg
SKU FD-C-DEF7X-01
EAN / GTIN-13 7340172702047
UPC 843276102043
Warranty period 2 years

Who should buy it

This case is ideal for users building high-end desktops with large motherboards, multi-GPU setups, or extensive storage. It may not suit those needing a compact case or small form factor builds.

Compatibility

Works with E-ATX, ATX, Micro ATX, Mini ITX, EE-ATX, SSI-CEB, and SSI-EEB motherboards. Requires ATX power supply with max length 250 mm. Supports GPU up to 530 mm and CPU coolers up to 185 mm.

  • Motherboard compatibility: E-ATX, ATX, Micro ATX, Mini ITX, EE-ATX, SSI-CEB, SSI-EEB
  • PSU compatibility: ATX
  • PSU max length: 250 mm
  • GPU max length: 530 mm
  • CPU cooler max height: 185 mm
  • Top radiator compatibility: 120, 140, 240, 280, 360, 420, 480
  • Front radiator compatibility: 120, 140, 240, 280
  • Bottom radiator compatibility: 120, 140, 240, 280

What's in the box

  • 2x Dynamic X2 GP-14 (front), 1x Dynamic X2 GP-14 (rear)

Frequently asked questions

What is the maximum GPU length supported by the Define 7 XL?

The Define 7 XL supports GPUs up to 530 mm in length.

How many storage drives can be installed in the Define 7 XL?

The Define 7 XL supports up to 18 HDDs and 5 SSDs mounts.

What is the maximum CPU cooler height for the Define 7 XL?

The Define 7 XL supports CPU coolers up to 185 mm in height.

Can the Define 7 XL support a 480mm radiator?

Yes, the Define 7 XL supports top radiators up to 480 mm.

What is the weight of the Define 7 XL case?

The Define 7 XL weighs 16.5 kg net and 20.2 kg gross.

Does the Define 7 XL come with fans included?

Yes, the Define 7 XL includes 2x Dynamic X2 GP-14 fans (front) and 1x Dynamic X2 GP-14 fan (rear).

What is the maximum length of the PSU that can be used in the Define 7 XL?

The Define 7 XL supports PSUs up to 250 mm in length.

How many expansion slots does the Define 7 XL have?

The Define 7 XL has 9 expansion slots.

Brand warranty: 2 years from the manufacturer — TechCure India helps you with the claim.

Why buy from TechCure India

  • Genuine product with brand warranty
  • GST invoice on every order
  • Insured delivery across India
  • Free compatibility check before dispatch — or build a full PC with our PC Builder

Specifications

BrandFractal Design
CategoryPC Cabinet
Model / MPNFD-C-DEF7X-01
TypeDefine 7 XL Black Solid
Compatible products01
ColorBlack
Dedicated 2.5" drive mounts5
5.25" drive mounts0
Combined 3.5"/2.5" drive mounts6
Expansion slots9
Front interface2x USB 2.0 Type-A, 2x USB Type-A 5Gbps, 1x USB Type-C 20Gbps, 1x Audio Jack, 1x Microphone Jack, 1x Power Button, 1x Reset Button
Captive thumbscrewsHDD brackets, SSD brackets, PSU bracket
Left side panelSteel
Right side panelSteel
Dust filtersFront Dust Filter, Top Dust Filter, Bottom Dust Filter, PSU Dust Filter
Cable grommetsYes
Hook-and-loop strapsCable routing space
Cable routing space30 mm
Front fan mounts4x 120 mm or 3x 140 mm
Top fan mounts4x 120 mm or 3x 140 mm
Bottom fan mounts2x 120/140 mm
Rear fan mounts1x 120/140 mm
Fans included2x Dynamic X2 GP-14 (front), 1x Dynamic X2 GP-14 (rear)
Motherboard compatibilityE-ATX, ATX, Micro ATX, Mini ITX, EE-ATX, SSI-CEB, SSI-EEB
PSU compatibilityATX
PSU max length250 mm
GPU max length530 mm
CPU cooler max height185 mm
Top radiator compatibility120, 140, 240, 280, 360, 420, 480
Front radiator compatibility120, 140, 240, 280
Bottom radiator compatibility120, 140, 240, 280
Rear radiator compatibility120
Product dimensions (L × W × H)604 x 240 x 566 mm
Package dimensions (L × W × H)646 x 357 x 708 mm
Volume (L)77.6 L
Net weight16.5 kg
Gross weight20.2 kg
SKUFD-C-DEF7X-01
EAN / GTIN-137340172702047
UPC843276102043
Warranty period2 years
ConditionNew, sealed box
WarrantyManufacturer warranty · details
InvoiceGST tax invoice (input credit available)
DeliveryInsured shipping to every serviceable pin code in India

Need help choosing?

Send us your current build or budget — we'll confirm compatibility and suggest the right pc cabinet for free.
