MSI MPG B650 Carbon WIFI Motherboard

₹34,588

MRP ₹49,770 (incl. of all taxes)

🚚 Free shipping across India on this product

EMI available at checkout (credit / debit card EMI via Razorpay)

✓ Sold by an MSI Authorized Channel Partner →

In stock · dispatched in 1–2 working days
Delivery across India in 2–8 days · insured

Genuine productBrand warranty · terms
GST invoiceClaim input credit
7-day returnsOn PC components
Insured deliveryAll over India

Secure payments by Razorpay · UPI, cards, net banking, EMI

Track an order Google reviews ↗

The MSI MPG B650 CARBON WIFI is a high-performance motherboard designed for gamers and PC builders using AMD Ryzen 7000 and 8000 series processors. It offers advanced features like Wi-Fi 6E, DDR5 memory support, and multiple high-speed storage options.

Full specifications ↓

Better options in the B650 chipset range

Same B650 chipset family, a little more money — here is what you get extra.

GIGABYTE B650E Aorus Master DDR5 AMD Motherboard
- Supports faster DDR5 memory
₹36,694+₹2,060 more

Highlights

Supports AMD Ryzen 8000/7000 Series Desktop Processors with Socket AM5
Offers DDR5 memory support up to 7800+ MHz (OC)
Features 4x M.2 slots with PCIe 5.0 and PCIe 4.0 speeds
Includes Wi-Fi 6E and Bluetooth 5.3 for wireless connectivity
Provides HDMI 2.1 and DisplayPort 1.4 for 4K and 8K display output
Supports RAID 0, RAID 1, and RAID 10 configurations for storage
Equipped with 2.5Gbps LAN for fast internet connectivity
Designed with carbon black color scheme and RGB lighting for style

Specifications

CHIPSET	AMD B650
CPU	Supports AMD Ryzen™ 8000/ 7000 Series Desktop Processors Socket AM5
MEMORY	4x DDR5, Maximum Memory Capacity 256GB Memory Support DDR5 7800+(OC)/ 7600(OC)/ 7400(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200(OC)/ 5000(OC)/ 4800(JEDEC) MHz Max. overclocking frequency: • 1DPC 1R Max speed up to 7800+ MHz • 1DPC 2R Max speed up to 6400+ MHz • 2DPC 1R Max speed up to 6400+ MHz • 2DPC 2R Max speed up to 5400+ MHz
ONBOARD GRAPHICS	1x HDMI™ Support HDMI™ 2.1 with HDR, maximum resolution of 4K 60Hz* 1x DisplayPort Support DP 1.4, maximum resolution of 8K 60Hz* *Available only on processors featuring integrated graphics. Graphics specifications may vary depending on the CPU installed.
SLOT	2x PCI-E x16 slot • Supports x16/x4 (For Ryzen™ 9000/ 7000 Series processors) • Supports x8/x4 (For Ryzen™ 8700/ 8600/ 8400 Series processors) • Supports x4/x2 (For Ryzen™ 8500/ 8300 Series processors) 1x PCI-E x1 slot PCI_E1 Gen PCIe 4.0 supports up to x16 (From CPU) PCI_E2 Gen PCIe 4.0 supports up to x4 (From CPU) PCI_E3 Gen PCIe 3.0 supports up to x1 (From Chipset) * PCI_E1, M2_2 & M2_3 share the bandwidth. PCI_E1 will run at x8 speed when installing devices in M2_2 or M2_3 slots. Please see manual for more details.
AUDIO	Realtek® ALC4080 Codec 7.1-Channel USB High Performance Audio Supports up to 32-Bit/384 kHz playback on front panel
STORAGE	4x M.2 M.2_1 Source (From CPU) supports up to PCIe 5.0 x4 , supports 2280/2260 devices M.2_2 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices M.2_3 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices M.2_4 Source (From Chipset) supports up to PCIe 4.0 x4 , supports 22110/2280/2260 devices 6x SATA 6G • M2_2 & M2_3 slots will not be available when installing Ryzen™ 8000 Series Desktop Processors
MULTI-GPU	AMD MULTI-GPU Support
RAID	Supports RAID 0, RAID 1 and RAID 10 for SATA storage devices Supports RAID 0, RAID 1 and RAID 10 for M.2 NVMe storage devices * SATA_A1~A2 do not support RAID function.
USB	2x USB 2.0 (Rear) 4x USB 2.0 (Front) 2x USB 5Gbps Type A (Front) 7x USB 10Gbps Type A (Rear) 1x USB 10Gbps Type C (Front) 1x USB 20Gbps Type C (Rear)
LAN	Realtek® RTL8125 2.5Gbps LAN
INTERNAL IO	1x Power Connector(ATX_PWR) 2x Power Connector(CPU_PWR) 1x CPU Fan 1x Pump Fan 5x System Fan 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x Tuning Controller connector(JDASH) 3x Addressable V2 RGB LED connector (JARGB_V2) 1x RGB LED connector(JRGB) 1x TPM pin header(Support TPM 2.0) 4x USB 2.0 ports 2x USB 5Gbps Type A ports 1x USB 10Gbps Type C ports
WIRELESS LAN & BLUETOOTH	AMD Wi-Fi 6E The Wireless module is pre-installed in the M.2 (Key-E) slot Supports MU-MIMO TX/RX Supports 20MHz, 40MHz, 80MHz,160MHz bandwidth in 2.4GHz/ 5GHz or 6GHz* bands Supports 802.11 a/ b/ g/ n/ ac/ ax Supports Bluetooth® 5.3** * Wi-Fi 6E 6GHz may depend on every country’s regulations and will be ready in Windows 11. ** Bluetooth 5.3 will be ready in Windows 10 build 21H1 and Windows 11.
LED FEATURE	4x EZ Debug LED 1x EZ LED Control switch
BACK PANEL PORTS	Clear CMOS / Flash BIOS Display Port 2.5G LAN USB 2.0 (Type-A) Audio Connectors HDMI™ USB 10Gbps (Type-A) USB 10Gbps (Type-A) USB 20Gbps (Type-C) Wi-Fi / Bluetooth Optical S/PDIF Out
OPERATING SYSTEM	Support for Windows® 11 64-bit, Windows® 10 64-bit
PCB INFO	ATX 243.84mmx304.8mm

Who should buy it

This motherboard is ideal for gamers and PC enthusiasts building high-performance systems with AMD Ryzen 7000/8000 series processors. It may not be suitable for users needing older CPU sockets or non-AMD platforms.

Compatibility

Works with AMD Ryzen 8000/7000 Series Desktop Processors on Socket AM5. Requires DDR5 memory modules. Compatible with Windows 11 64-bit and Windows 10 64-bit operating systems.

Supports AMD Ryzen™ 8000/ 7000 Series Desktop Processors
Supports AMD Ryzen™ 8000/ 7000 Series Desktop Processors Socket AM5
Supports DDR5 7800+(OC)/ 7600(OC)/ 7400(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200(OC)/ 5000(OC)/ 4800(JEDEC) MHz
Supports 802.11 a/ b/ g/ n/ ac/ ax
Supports Bluetooth® 5.3
Supports Windows® 11 64-bit, Windows® 10 64-bit
Supports RAID 0, RAID 1 and RAID 10 for SATA storage devices
Supports RAID 0, RAID 1 and RAID 10 for M.2 NVMe storage devices

What's in the box

PCB INFO
ATX
243.84mmx304.8mm

Frequently asked questions

What is the maximum memory speed supported by the MSI MPG B650 CARBON WIFI motherboard?

The motherboard supports DDR5 memory up to 7800+ MHz (OC) for 1DPC 1R configuration.

Does the MSI MPG B650 CARBON WIFI support Wi-Fi 6E and Bluetooth 5.3?

Yes, it supports Wi-Fi 6E and Bluetooth 5.3 as per the specifications.

What is the maximum resolution supported by the HDMI and DisplayPort on the MSI MPG B650 CARBON WIFI?

HDMI supports up to 4K 60Hz with HDR, and DisplayPort supports up to 8K 60Hz.

How many M.2 slots does the MSI MPG B650 CARBON WIFI have and what are their speeds?

It has 4x M.2 slots: M.2_1 supports PCIe 5.0 x4, while M.2_2, M.2_3, and M.2_4 support PCIe 4.0 x4.

Can the MSI MPG B650 CARBON WIFI support RAID configurations for M.2 NVMe drives?

Yes, it supports RAID 0, RAID 1, and RAID 10 for M.2 NVMe storage devices.

Brand warranty: 3 years from the manufacturer — TechCure India helps you with the claim.

Why buy from TechCure India

Genuine product with brand warranty
GST invoice on every order
Insured delivery across India
Free compatibility check before dispatch — or build a full PC with our PC Builder

Specifications

Brand	MSI
Category	Motherboard
Model / MPN	MPG-B650-CARBON-WIFI
CHIPSET	AMD B650
CPU	Supports AMD Ryzen™ 8000/ 7000 Series Desktop Processors
MEMORY	4x DDR5, Maximum Memory Capacity 256GB
ONBOARD GRAPHICS	1x HDMI™
SLOT	2x PCI-E x16 slot
AUDIO	Realtek® ALC4080 Codec
STORAGE	4x M.2
MULTI-GPU	AMD MULTI-GPU Support
RAID	Supports RAID 0, RAID 1 and RAID 10 for SATA storage devices
USB	2x USB 2.0 (Rear)
LAN	Realtek® RTL8125 2.5Gbps LAN
INTERNAL IO	1x Power Connector(ATX_PWR)
WIRELESS LAN & BLUETOOTH	AMD Wi-Fi 6E
LED FEATURE	4x EZ Debug LED
BACK PANEL PORTS	Clear CMOS / Flash BIOS
OPERATING SYSTEM	Support for Windows® 11 64-bit, Windows® 10 64-bit
PCB INFO	ATX
Condition	New, sealed box
Warranty	Manufacturer warranty · details
Invoice	GST tax invoice (input credit available)
Delivery	Insured shipping to every serviceable pin code in India
