The Smart BX1 750W is a reliable power supply unit designed for desktop computers. It delivers stable power with efficient performance for everyday computing needs.

Full specifications ↓

Highlights

Meets 80 PLUS Bronze efficiency rating at 88% power efficiency
Features a 120mm hydraulic bearing fan for near silent operation
Built with premium Japanese main capacitors for durability
Offers a 5-year warranty for long-term reliability
Supports ATX 12V v2.3 and EPS v2.92 standards
Provides low ripple noise below 80mV on +12V
Operates efficiently in temperatures from 5°C to 40°C
Works with input voltage range of 100V – 240V~

Specifications

P/N	PS-SPD-0750NNFABx-1
MODEL	SPD-750AH2NKB
TYPE	ATX 12V v2.3 and EPS v2.92
FORM FACTOR	ATX
MAX OUTPUT CAPACITY	750W
COLOR	Black
DIMENSIONS	150mm(W) x 86mm(H) x 140mm(D)
PFC (POWER FACTOR CORRECTION)	Active PFC
POWER GOOD SIGNAL	100-500 msec
HOLD UP TIME	> 16msec at 70% of full load
INPUT CURRENT	12A max.
INPUT FREQUENCY RANGE	50Hz - 60Hz
INPUT VOLTAGE	100V – 240V~
OPERATING TEMPERTURE	5°C to + 40°C
OPERATING HUMIDITY	20% to 85%, non-condensing
STORAGE TEMPERTURE	-40°C to + 55°C
STORAGE HUMIDITY	10% to 95%, non-condensing
COOLING SYSTEM	12cm Hydraulic bearing fan
EFFICIENCY	Meet 80 PLUS®Bronze at 115Vac input.
MTBF	100,000 hrs minimum
SAFETY APPROVAL	CE/CB/TUV/ UL/ FCC/ BSMI
PCI-E 6+2PIN	4

Who should buy it

This power supply is ideal for users seeking a stable and quiet power solution for their desktop systems. It may not be suitable for those needing a power supply with higher wattage or specific compatibility beyond ATX 12V v2.3 and EPS v2.92.

Compatibility

The Smart BX1 750W is compatible with ATX 12V v2.3 and EPS v2.92 systems. It requires a standard ATX case and works with input voltages from 100V to 240V.

ATX 12V v2.3 and EPS v2.92

Frequently asked questions

What is the efficiency rating of the Thermaltake Smart BX1 750W?

The Smart BX1 750W meets 80 PLUS Bronze efficiency rating at 88% power efficiency.

How many PCIe 6+2 pin connectors does it have?

It has 4 PCIe 6+2 pin connectors.

What is the operating temperature range?

It operates between 5°C to 40°C.

What is the warranty period for this power supply?

It comes with a 5-year warranty.

What type of fan does it use?

It uses a 120mm hydraulic bearing fan.

What is the input voltage range?

It supports input voltage from 100V to 240V~.

What is the maximum output capacity?

The maximum output capacity is 750W.

What is the color of the power supply?

The power supply is black.

Brand warranty: 5 years from the manufacturer — TechCure India helps you with the claim.

Why buy from TechCure India

Genuine product with brand warranty
GST invoice on every order
Insured delivery across India
Free compatibility check before dispatch — or build a full PC with our PC Builder

Specifications

Brand	Thermaltake
Category	Power Supply Unit
Model / MPN	SPD-750AH2NKB
P/N	PS-SPD-0750NNFABx-1
MODEL	SPD-750AH2NKB
TYPE	ATX 12V v2.3 and EPS v2.92
FORM FACTOR	ATX
MAX OUTPUT CAPACITY	750W
COLOR	Black
DIMENSIONS	150mm(W) x 86mm(H) x 140mm(D)
PFC (POWER FACTOR CORRECTION)	Active PFC
POWER GOOD SIGNAL	100-500 msec
HOLD UP TIME	> 16msec at 70% of full load
INPUT CURRENT	12A max.
INPUT FREQUENCY RANGE	50Hz - 60Hz
INPUT VOLTAGE	100V – 240V~
OPERATING TEMPERTURE	5°C to + 40°C
OPERATING HUMIDITY	20% to 85%, non-condensing
STORAGE TEMPERTURE	-40°C to + 55°C
STORAGE HUMIDITY	10% to 95%, non-condensing
COOLING SYSTEM	12cm Hydraulic bearing fan
EFFICIENCY	Meet 80 PLUS®Bronze at 115Vac input.
MTBF	100,000 hrs minimum
SAFETY APPROVAL	CE/CB/TUV/ UL/ FCC/ BSMI
PCI-E 6+2PIN	4
